R98減速機詳細信息
R98減速機
訂購熱線：13360667204
R98減速機傳動比計算：齒輪減速馬達
輸送帶參數：輪子直徑200，負載4.5噸，一分鐘走10米
10米÷（0.2輪子直徑×3.14）=15.9轉每分鐘
4.5噸換算成N=45000N
45000×0.1輪子半徑×0.06摩擦系數=270N.m
通常確保萬無一失，我們會把輸出扭矩放大兩倍270×2=540N.m
電機轉數1400÷輸出轉數15.9=88比
540N.m輸出扭矩÷88比=6.1N.m電機扭矩
6.1N.m電機扭矩換算成功率1KW以上
對應的R98減速機選型參數：
型號：R98-B1.5KW
減速比：92.48
輸出轉數：15轉每分鐘
輸出扭矩：920N.m
安全系數：3.20
R98減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機
R98臥式硬齒面斜齒輪減速機型號：
R97FDM100L4,R97FDM100LC4,R97FDM100LS4,R97FDM100M4,R97FDM112M4,R97FDM132L4,R97FDM132M4,R97FDM132MC4,R97FDM132ML4,R97FDM132S4,R97FDM160L4,R97FDM160M4,R97FDM160MC4,R97FDM160S4,R97FDM180L4,R97FDM180LC4,R97FDM180M4,R97FDM180S4,R97FDM200L4,R97FDM71D4,R97FDM71MS4,R97FDM71S4,R97FDM80K4,R97FDM80M4,R97FDM80MK4,R97FDM80N4,R97FDM80S4,R97FDM90L4,R97FDM90M4,R97FDM90S4,R97FDR100L4,R97FDR100LC4,R97FDR100LS4,R97FDR100M4,R97FDR112M4,R97FDR132L4,R97FDR132M4,R97FDR132MC4,R97FDR132ML4,R97FDR132S4,R97FDR160L4,R97FDR160M4,R97FDR160MC4,R97FDR160S4,R97FDR180L4,R97FDR180LC4,R97FDR180M4,R97FDR180S4,R97FDR200L4,R97FDR71D4,R97FDR71MS4,R97FDR71S4,R97FDR80K4,R97FDR80M4,R97FDR80MK4,R97FDR80N4,R97FDR80S4,R97FDR90L4,R97FDR90M4,R97FDR90S4,R97FDRE100L4,R97FDRE100LC4,R97FDRE100LS4,R97FDRE100M4,R97FDRE112M4,R97FDRE132L4,R97FDRE132M4,R97FDRE132MC4,R97FDRE132ML4,R97FDRE132S4,R97FDRE160L4,R97FDRE160M4,R97FDRE160MC4,R97FDRE160S4,R97FDRE180L4,R97FDRE180LC4,R97FDRE180M4,R97FDRE180S4,R97FDRE200L4,R97FDRE71D4,R97FDRE71MS4,R97FDRE71S4,R97FDRE80K4,R97FDRE80M4,R97FDRE80MK4,R97FDRE80N4,R97FDRE80S4,R97FDRE90L4,R97FDRE90M4,R97FDRE90S4,R97FDRN100L4,R97FDRN100LC4,R97FDRN100LS4,R97FDRN100M4,R97FDRN112M4,R97FDRN132L4,R97FDRN132M4,R97FDRN132MC4,R97FDRN132ML4,R97FDRN132S4,R97FDRN160L4,R97FDRN160M4,R97FDRN160MC4,R97FDRN160S4,R97FDRN180L4,R97FDRN180LC4,R97FDRN180M4,R97FDRN180S4,R97FDRN200L4,R97FDRN71D4,R97FDRN71MS4,R97FDRN71S4,R97FDRN80K4,R97FDRN80M4,R97FDRN80MK4,R97FDRN80N4,R97FDRN80S4,R97FDRN90L4,R97FDRN90M4,R97FDRN90S4,R97FDRS100L4,R97FDRS100LC4,R97FDRS100LS4,R97FDRS100M4,R97FDRS112M4,R97FDRS132L4,R97FDRS132M4,R97FDRS132MC4,R97FDRS132ML4,R97FDRS132S4,R97FDRS160L4,R97FDRS160M4,R97FDRS160MC4,R97FDRS160S4,R97FDRS180L4,R97FDRS180LC4,R97FDRS180M4,R97FDRS180S4,R97FDRS200L4,R97FDRS71D4,R97FDRS71MS4,R97FDRS71S4,R97FDRS80K4,R97FDRS80M4,R97FDRS80MK4,R97FDRS80N4,R97FDRS80S4,R97FDRS90L4,R97FDRS90M4,R97FDRS90S4,R97FDT100L4,R97FDT100LC4,R97FDT100LS4,R97FDT100M4,R97FDT112M4,R97FDT132L4,R97FDT132M4,R97FDT132MC4,R97FDT132ML4,R97FDT132S4,R97FDT160L4,R97FDT160M4,R97FDT160MC4,R97FDT160S4,R97FDT180L4,R97FDT180LC4,R97FDT180M4,R97FDT180S4,R97FDT200L4,R97FDT71D4,R97FDT71MS4,R97FDT71S4,R97FDT80K4,R97FDT80M4,R97FDT80MK4,R97FDT80N4,R97FDT80S4,R97FDT90L4,R97FDT90M4,R97FDT90S4,R97FDV100L4,R97FDV100LC4,R97FDV100LS4,R97FDV100M4,R97FDV112M4,R97FDV132L4,R97FDV132M4,R97FDV132MC4,R97FDV132ML4,R97FDV132S4,R97FDV160L4,R97FDV160M4,R97FDV160MC4,R97FDV160S4,R97FDV180L4,R97FDV180LC4,R97FDV180M4,R97FDV180S4,R97FDV200L4,R97FDV71D4,R97FDV71MS4,R97FDV71S4,R97FDV80K4,R97FDV80M4,R97FDV80MK4,R97FDV80N4,R97FDV80S4,R97FDV90L4,R97FDV90M4,R97FDV90S4,R97FDVE100L4,R97FDVE100LC4,R97FDVE100LS4,R97FDVE100M4,R97FDVE112M4,R97FDVE132L4,R97FDVE132M4,R97FDVE132MC4,R97FDVE132ML4,R97FDVE132S4,R97FDVE160L4,R97FDVE160M4,R97FDVE160MC4,R97FDVE160S4,R97FDVE180L4,R97FDVE180LC4,R97FDVE180M4,R97FDVE180S4,R97FDVE200L4,R97FDVE71D4,R97FDVE71MS4,R97FDVE71S4,R97FDVE80K4,R97FDVE80M4,R97FDVE80MK4,R97FDVE80N4,R97FDVE80S4,R97FDVE90L4,R97FDVE90M4,R97FDVE90S4,R97F-Y0.55KW,R97F-Y0.75KW,R97F-Y1.1KW,R97F-Y1.5KW,R97F-Y100M4,R97F-Y112M4,R97F-Y11KW,R97F-Y132M4,R97F-Y15KW,R97F-Y160M4,R97F-Y18.5KW,R97F-Y180M4,R97F-Y2.2KW,R97F-Y200M4,R97F-Y22KW,R97F-Y30KW,R97F-Y3KW,R97F-Y4KW,R97F-Y5.5KW,R97F-Y7.5KW,R97F-Y80M4,R97F-Y90M4,R97F-YEJ0.55KW,R97F-YEJ0.75KW,R97F-YEJ1.1KW,R97F-YEJ1.5KW,R97F-YEJ100M4,R97F-YEJ112M4,R97F-YEJ11KW,R97F-YEJ132M4,R97F-YEJ15KW,R97F-YEJ160M4,R97F-YEJ18.5KW,R97F-YEJ180M4,R97F-YEJ2.2KW,R97F-YEJ200M4,R97F-YEJ22KW,R97F-YEJ30KW,R97F-YEJ3KW,R97F-YEJ4KW,R97F-YEJ5.5KW,R97F-YEJ7.5KW,R97F-YEJ80M4,R97F-YEJ90M4,R97F-YVP0.55KW,R97F-YVP0.75KW,R97F-YVP1.1KW,R97F-YVP1.5KW,R97F-YVP100M4,R97F-YVP112M4,R97F-YVP11KW,R97F-YVP132M4,R97F-YVP15KW,R97F-YVP160M4,R97F-YVP18.5KW,R97F-YVP180M4,R97F-YVP2.2KW,R97F-YVP200M4,R97F-YVP22KW,R97F-YVP30KW,R97F-YVP3KW,R97F-YVP4KW,R97F-YVP5.5KW,R97F-YVP7.5KW,R97F-YVP80M4,R97F-YVP90M4,R97F-YVPEJ0.55KW,R97F-YVPEJ0.75KW,R97F-YVPEJ1.1KW,R97F-YVPEJ1.5KW,R97F-YVPEJ100M4,R97F-YVPEJ112M4,R97F-YVPEJ11KW,R97F-YVPEJ132M4,R97F-YVPEJ15KW,R97F-YVPEJ160M4,R97F-YVPEJ18.5KW,R97F-YVPEJ180M4,R97F-YVPEJ2.2KW,R97F-YVPEJ200M4,R97F-YVPEJ22KW,R97F-YVPEJ30KW,R97F-YVPEJ3KW,R97F-YVPEJ4KW,R97F-YVPEJ5.5KW,R97F-YVPEJ7.5KW,R97F-YVPEJ80M4,R97F-YVPEJ90M4。
R97系列減速機參數大全：同軸斜齒輪減速電機
R97F減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y0.55KW | 289.74 | 0.55kw | 110kg | 27700N |
| R97F-Y0.55KW | 255.71 | 0.55kw | 110kg | 27900N |
| R97F-Y0.55KW | 241.25 | 0.55kw | 110kg | 28000N |
| R97F-Y0.55KW | 216.28 | 0.55kw | 110kg | 28100N |
R97F減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y0.75KW | 289.74 | 0.75kw | 110kg | 27700N |
| R97F-Y0.75KW | 255.71 | 0.75kw | 110kg | 27900N |
| R97F-Y0.75KW | 241.25 | 0.75kw | 110kg | 28000N |
| R97F-Y0.75KW | 216.28 | 0.75kw | 110kg | 28100N |
| R97F-Y0.75KW | 186.3 | 0.75kw | 110kg | 28300N |
| R97F-Y0.75KW | 170.02 | 0.75kw | 110kg | 28300N |
R97F減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y1.1KW | 255.71 | 1.1kw | 115kg | 26700N |
| R97F-Y1.1KW | 241.25 | 1.1kw | 115kg | 27100N |
| R97F-Y1.1KW | 216.28 | 1.1kw | 115kg | 27500N |
| R97F-Y1.1KW | 186.3 | 1.1kw | 115kg | 27800N |
| R97F-Y1.1KW | 170.02 | 1.1kw | 115kg | 27900N |
| R97F-Y1.1KW | 150.78 | 1.1kw | 115kg | 28100N |
| R97F-Y1.1KW | 126.75 | 1.1kw | 115kg | 28300N |
| R97F-Y1.1KW | 116.48 | 1.1kw | 115kg | 28300N |
R97F減速機配1.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y1.5KW | 255.71 | 1.5kw | 115kg | 23400N |
| R97F-Y1.5KW | 241.25 | 1.5kw | 115kg | 24300N |
| R97F-Y1.5KW | 216.28 | 1.5kw | 115kg | 25500N |
| R97F-Y1.5KW | 186.3 | 1.5kw | 115kg | 26700N |
| R97F-Y1.5KW | 170.02 | 1.5kw | 115kg | 27300N |
| R97F-Y1.5KW | 150.78 | 1.5kw | 115kg | 27600N |
| R97F-Y1.5KW | 126.75 | 1.5kw | 115kg | 27900N |
| R97F-Y1.5KW | 116.48 | 1.5kw | 115kg | 28000N |
| R97F-Y1.5KW | 103.44 | 1.5kw | 115kg | 28200N |
| R97F-Y1.5KW | 92.48 | 1.5kw | 115kg | 28300N |
R97F減速機配2.2KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y2.2KW | 216.28 | 2.2kw | 120kg | 3580N |
| R97F-Y2.2KW | 186.3 | 2.2kw | 120kg | 22300N |
| R97F-Y2.2KW | 170.02 | 2.2kw | 120kg | 23800N |
| R97F-Y2.2KW | 150.78 | 2.2kw | 120kg | 25300N |
| R97F-Y2.2KW | 126.75 | 2.2kw | 120kg | 26800N |
| R97F-Y2.2KW | 116.48 | 2.2kw | 120kg | 27300N |
| R97F-Y2.2KW | 103.44 | 2.2kw | 120kg | 27600N |
| R97F-Y2.2KW | 92.48 | 2.2kw | 120kg | 27800N |
| R97F-Y2.2KW | 83.15 | 2.2kw | 120kg | 28000N |
| R97F-Y2.2KW | 72.17 | 2.2kw | 120kg | 28100N |
| R97F-Y2.2KW | 65.21 | 2.2kw | 120kg | 27700N |
| R97F-Y2.2KW | 59.92 | 2.2kw | 120kg | 27100N |
| R97F-Y2.2KW | 53.21 | 2.2kw | 120kg | 26200N |
| R97F-Y2.2KW | 47.58 | 2.2kw | 120kg | 25300N |
R97F減速機配3KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y3KW | 150.78 | 3kw | 125kg | 16200N |
| R97F-Y3KW | 126.75 | 3kw | 125kg | 23600N |
| R97F-Y3KW | 116.48 | 3kw | 125kg | 24700N |
| R97F-Y3KW | 103.44 | 3kw | 125kg | 25900N |
| R97F-Y3KW | 92.48 | 3kw | 125kg | 26800N |
| R97F-Y3KW | 83.15 | 3kw | 125kg | 27300N |
| R97F-Y3KW | 72.17 | 3kw | 125kg | 27700N |
| R97F-Y3KW | 65.21 | 3kw | 125kg | 27000N |
| R97F-Y3KW | 59.92 | 3kw | 125kg | 26400N |
| R97F-Y3KW | 53.21 | 3kw | 125kg | 25600N |
| R97F-Y3KW | 47.58 | 3kw | 125kg | 24800N |
| R97F-Y3KW | 42.78 | 3kw | 125kg | 24000N |
| R97F-Y3KW | 37.13 | 3kw | 125kg | 23100N |
| R97F-Y3KW | 33.25 | 3kw | 125kg | 22400N |
R97F減速機配4KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y4KW | 116.48 | 4kw | 140kg | 15500N |
| R97F-Y4KW | 103.44 | 4kw | 140kg | 22600N |
| R97F-Y4KW | 92.48 | 4kw | 140kg | 24300N |
| R97F-Y4KW | 83.15 | 4kw | 140kg | 25500N |
| R97F-Y4KW | 72.17 | 4kw | 140kg | 26600N |
| R97F-Y4KW | 65.21 | 4kw | 140kg | 26000N |
| R97F-Y4KW | 59.92 | 4kw | 140kg | 25400N |
| R97F-Y4KW | 53.21 | 4kw | 140kg | 24700N |
| R97F-Y4KW | 47.58 | 4kw | 140kg | 24000N |
| R97F-Y4KW | 42.78 | 4kw | 140kg | 23300N |
| R97F-Y4KW | 37.13 | 4kw | 140kg | 22400N |
| R97F-Y4KW | 33.25 | 4kw | 140kg | 21800N |
R97F減速機配5.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y5.5KW | 83.15 | 5.5kw | 145kg | 18900N |
| R97F-Y5.5KW | 72.17 | 5.5kw | 145kg | 21900N |
| R97F-Y5.5KW | 65.21 | 5.5kw | 145kg | 24600N |
| R97F-Y5.5KW | 59.92 | 5.5kw | 145kg | 24200N |
| R97F-Y5.5KW | 53.21 | 5.5kw | 145kg | 23600N |
| R97F-Y5.5KW | 47.58 | 5.5kw | 145kg | 23000N |
| R97F-Y5.5KW | 42.78 | 5.5kw | 145kg | 22400N |
| R97F-Y5.5KW | 37.13 | 5.5kw | 145kg | 21600N |
| R97F-Y5.5KW | 33.25 | 5.5kw | 145kg | 21000N |
| R97F-Y5.5KW | 27.58 | 5.5kw | 145kg | 20000N |
| R97F-Y5.5KW | 32.05 | 5.5kw | 145kg | 20900N |
| R97F-Y5.5KW | 27.19 | 5.5kw | 145kg | 20000N |
| R97F-Y5.5KW | 25.03 | 5.5kw | 145kg | 19500N |
| R97F-Y5.5KW | 22.37 | 5.5kw | 145kg | 19800N |
| R97F-Y5.5KW | 20.14 | 5.5kw | 145kg | 18400N |
| R97F-Y5.5KW | 18.24 | 5.5kw | 145kg | 17900N |
| R97F-Y5.5KW | 16.17 | 5.5kw | 145kg | 17300N |
R97F減速機配7.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97Y7.5KW | 59.92 | 7.5kw | 155kg | 20900N |
| R97Y7.5KW | 53.21 | 7.5kw | 155kg | 22200N |
| R97Y7.5KW | 47.58 | 7.5kw | 155kg | 21700N |
| R97Y7.5KW | 42.78 | 7.5kw | 155kg | 21300N |
| R97Y7.5KW | 37.13 | 7.5kw | 155kg | 20700N |
| R97Y7.5KW | 33.25 | 7.5kw | 155kg | 20200N |
| R97Y7.5KW | 27.58 | 7.5kw | 155kg | 19300N |
| R97Y7.5KW | 32.05 | 7.5kw | 155kg | 20000N |
| R97Y7.5KW | 27.19 | 7.5kw | 155kg | 19200N |
| R97Y7.5KW | 25.03 | 7.5kw | 155kg | 19800N |
| R97Y7.5KW | 22.37 | 7.5kw | 155kg | 18300N |
| R97Y7.5KW | 20.14 | 7.5kw | 155kg | 17900N |
| R97Y7.5KW | 18.24 | 7.5kw | 155kg | 17400N |
R97F減速機配11KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y11KW | 42.78 | 11kw | 180kg | 16600N |
| R97F-Y11KW | 37.13 | 11kw | 180kg | 18900N |
| R97F-Y11KW | 33.25 | 11kw | 180kg | 18600N |
| R97F-Y11KW | 27.58 | 11kw | 180kg | 18000N |
| R97F-Y11KW | 25.03 | 11kw | 180kg | 17700N |
| R97F-Y11KW | 22.37 | 11kw | 180kg | 17300N |
| R97F-Y11KW | 20.14 | 11kw | 180kg | 16900N |
| R97F-Y11KW | 18.24 | 11kw | 180kg | 16500N |
| R97F-Y11KW | 16.17 | 11kw | 180kg | 16100N |
| R97F-Y11KW | 14.62 | 11kw | 180kg | 15700N |
| R97F-Y11KW | 12.39 | 11kw | 180kg | 15000N |
| R97F-Y11KW | 10.83 | 11kw | 180kg | 14500N |
| R97F-Y11KW | 9.29 | 11kw | 180kg | 14200N |
| R97F-Y11KW | 8.39 | 11kw | 180kg | 13800N |
| R97F-Y11KW | 7.12 | 11kw | 180kg | 13200N |
| R97F-Y11KW | 6.21 | 11kw | 180kg | 12600N |
R97F減速機配15KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y15KW | 27.58 | 15kw | 215kg | 16500N |
| R97F-Y15KW | 25.03 | 15kw | 215kg | 16300N |
| R97F-Y15KW | 22.37 | 15kw | 215kg | 16100N |
| R97F-Y15KW | 20.14 | 15kw | 215kg | 15800N |
| R97F-Y15KW | 18.24 | 15kw | 215kg | 15600N |
| R97F-Y15KW | 16.17 | 15kw | 215kg | 15200N |
| R97F-Y15KW | 14.62 | 15kw | 215kg | 14900N |
| R97F-Y15KW | 12.39 | 15kw | 215kg | 14400N |
| R97F-Y15KW | 10.83 | 15kw | 215kg | 14000N |
| R97F-Y15KW | 9.29 | 15kw | 215kg | 13800N |
| R97F-Y15KW | 8.39 | 15kw | 215kg | 13400N |
| R97F-Y15KW | 7.12 | 15kw | 215kg | 12800N |
| R97F-Y15KW | 6.21 | 15kw | 215kg | 12400N |
R97F減速機配18.5KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y18.5KW | 20.14 | 18.5kw | 225kg | 14900N |
| R97F-Y18.5KW | 18.24 | 18.5kw | 225kg | 14700N |
| R97F-Y18.5KW | 16.17 | 18.5kw | 225kg | 14500N |
| R97F-Y18.5KW | 14.62 | 18.5kw | 225kg | 14200N |
| R97F-Y18.5KW | 12.39 | 18.5kw | 225kg | 13800N |
| R97F-Y18.5KW | 10.83 | 18.5kw | 225kg | 13500N |
| R97F-Y18.5KW | 9.29 | 18.5kw | 225kg | 13400N |
| R97F-Y18.5KW | 8.39 | 18.5kw | 225kg | 13100N |
| R97F-Y18.5KW | 7.12 | 18.5kw | 225kg | 12600N |
| R97F-Y18.5KW | 6.21 | 18.5kw | 225kg | 12100N |
| R97F-Y18.5KW | 5.2 | 18.5kw | 225kg | 11600N |
| R97F-Y18.5KW | 4.5 | 18.5kw | 225kg | 11100N |
R97F減速機配22KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y22KW | 20.14 | 22kw | 245kg | 14000N |
| R97F-Y22KW | 18.24 | 22kw | 245kg | 13900N |
| R97F-Y22KW | 16.17 | 22kw | 245kg | 13700N |
| R97F-Y22KW | 14.62 | 22kw | 245kg | 13600N |
| R97F-Y22KW | 12.39 | 22kw | 245kg | 13300N |
| R97F-Y22KW | 10.83 | 22kw | 245kg | 13000N |
| R97F-Y22KW | 9.29 | 22kw | 245kg | 13100N |
| R97F-Y22KW | 8.39 | 22kw | 245kg | 12800N |
| R97F-Y22KW | 7.12 | 22kw | 245kg | 12300N |
| R97F-Y22KW | 6.21 | 22kw | 245kg | 11900N |
| R97F-Y22KW | 5.2 | 22kw | 245kg | 11400N |
| R97F-Y22KW | 4.5 | 22kw | 245kg | 10900N |
R97F減速機配30KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R97F-Y30KW | 14.62 | 30kw | 345kg | 12000N |
| R97F-Y30KW | 12.39 | 30kw | 345kg | 11900N |
| R97F-Y30KW | 10.83 | 30kw | 345kg | 11800N |
| R97F-Y30KW | 9.29 | 30kw | 345kg | 12300N |
| R97F-Y30KW | 8.39 | 30kw | 345kg | 12100N |
| R97F-Y30KW | 7.12 | 30kw | 345kg | 11700N |
| R97F-Y30KW | 6.21 | 30kw | 345kg | 11300N |
| R97F-Y30KW | 5.2 | 30kw | 345kg | 10900N |
| R97F-Y30KW | 4.5 | 30kw | 345kg | 10500N |
R98減速機生產工廠展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約
推薦類似型號：R88減速機
關鍵詞:同向減速機臥式配電機一體式_R系列減速電機_R系列減速機_R系列減速器_同向減速器_GR型減速機_R向減速機_R系列斜齒輪減速機_GR系列減速機_R型減速機_GR系列斜齒輪減速機
R系列減速機型號：R18減速機,R28減速機,R38減速機,R48減速機,R58減速機,R68減速機,R78減速機,R88減速機,R98減速機,R108減速機,R138減速機,R148減速機,R168減速機
R系列齒輪減速馬達可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-132KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: R98減速機 R97臥式硬齒面斜齒輪減速機 R97系列減速機 R97減速機傳動比 R97減速機選型參數 R97減速機CAD三維圖
